Crushing & Grinding Machine
Sealed Continuous Sample Preparation Pulverizer with Continuous Feeding and Discharging System
Item Number : KT-LX
Price varies based on specs and customizations
Shipping:
Contact us to get shipping details Enjoy On-time Dispatch Guarantee.
Why Choose Us
Easy ordering process, quality products, and dedicated support for your business success.
Product Overview
This continuous sample preparation pulverizer represents an advanced engineering solution designed to replace conventional, labor-intensive batch grinding mills in modern analytical laboratories. By integrating continuous material feeding, high-energy vibratory grinding, automated sample division, and direct hermetic sample collection into a single, enclosed architecture, this system streamlines the sample reduction workflow. Laboratory technicians no longer need to manually load individual grinding bowls, disassemble heavy clamping mechanisms, or perform repetitive manual cleanouts between runs. The unit processes bulk samples continuously, reducing labor overhead while boosting daily analytical throughput.
Engineered specifically for high-capacity industrial quality control and assay environments, the equipment serves vital sectors such as coal mining, thermal power generation, metallurgy, geological exploration, commercial commodity inspection, and clean energy material processing. Its continuous-flow design allows direct coupling with primary coarse crushers, establishing an uninterrupted, automated material reduction pipeline from raw feed to analytical-grade powder. This multi-stage operational integration significantly lowers the potential for human error and guarantees that sample integrity is preserved across every stage of processing.
Operational durability and environmental safety define the core value proposition of this continuous milling system. Fabricated with a heavy-gauge structural frame and a contact pathway constructed entirely from premium 304 stainless steel, the machine resists mechanical wear while eliminating unwanted heavy-metal and iron cross-contamination. Complete hermetic sealing, paired with an intelligent variable-frequency air-purge evacuation circuit, prevents hazardous fugitive dust emissions, maintaining a pristine testing environment and safeguarding laboratory personnel during continuous, heavy-duty operation.
Key Features
- Automated Continuous Feeding and Discharge: Designed with a high-capacity receiving hopper and an engineered vibratory chute mechanism that feeds material smoothly into the grinding zone, this unit allows non-stop pulverizing and automatic sample discharging without pausing machine operation.
- Integrated Sample Division and Direct Bottling: The pulverized material is routed dynamically through an internal precision riffler/divider that automatically apportions representative sample splits directly into sealed sample containers, eliminating manual riffling and handling discrepancies.
- High-Fineness Grinding with 99.98% Sieve Compliance: The high-frequency vibratory bowl geometry pulverizes raw feed up to 15 mm down to an analytical fineness of 80 to 200 mesh (<0.2 mm) with an exceptional 99.98% passing rate, ensuring dependable uniformity for downstream XRF, ICP, and proximate analyses.
- Sanitary 304 Stainless Steel Material Pathway: All interior surfaces, grinding bowls, transfer channels, and sample collection points in contact with the material are precision-machined from certified 304 stainless steel, preventing iron contamination and resisting corrosive mineral particulates.
- Variable-Frequency Induced Draft and Air-Purge Cleaning: Equipped with an inverter-driven pneumatic purge system that continuously clears internal channels, the pulverizer prevents particulate accumulation, stops caking, and delivers rapid self-cleaning to eliminate cross-batch contamination.
- Anti-Caking Dynamic Impact Mechanics: Advanced vibrational resonance vectors transfer energy efficiently to eliminate material sticking and bowl caking, facilitating the seamless grinding of complex coals, moist minerals, and challenging industrial ores.
- Hermetically Sealed Eco-Friendly Architecture: Fully enclosed structural panels and tight mechanical seals retain all fine dust internally, creating a zero-leakage operating cycle that meets demanding occupational health and dust mitigation standards.
- Direct Upstream Crusher Interfacing: The unit is mechanically and electronically configured to link seamlessly with primary jaw crushers or roll crushers, consolidating primary crushing, continuous pulverization, sample splitting, and bottling into a unified workstation.
Applications
| Application | Description | Key Benefit |
|---|---|---|
| Coal Mining & Washery Quality Control | Continuous milling of raw coal, washed coal, and middlings for proximate, ash, and calorific value testing. | High throughput handles large sample batches rapidly without moisture loss or coal dust release. |
| Thermal Power Generation Fuel Testing | Rapid sample pulverizing of pulverized fuel feeds and boiler slag to assess combustion efficiency and sulfur content. | Automated dividing delivers ready-to-analyze sample splits directly into sealed containers for instant testing. |
| Metallurgical Smelting & Blast Furnace Operations | Pulverizing iron ores, sinter, coke, limestone, and alloy precursors to analytical fineness for spectroscopic monitoring. | Heavy-duty construction handles abrasive minerals while 304 stainless surfaces eliminate iron contamination. |
| Commercial Inspection & Third-Party Assaying | Multi-client commodity inspection of bulk imported/exported mineral cargoes under strict turnaround deadlines. | Continuous flow speeds up sample processing while automated air purging prevents inter-sample cross-contamination. |
| Geological Exploration & Ore Extraction | Grinding core samples, geological rock chips, and survey trench materials for precious and base metal assaying. | Achieves <0.2 mm particle sizing with 99.98% sieving consistency for highly reproducible chemical digestion. |
| Solid Waste & Environmental Ash Characterization | Preparation of industrial fly ash, slag by-products, and incinerator residues for leaching and heavy-metal screening. | Hermetically sealed negative-pressure grinding protects testing operators from hazardous fine dust inhalation. |
| New Energy & Battery Mineral Processing | Grinding graphite ores, synthetic carbon, and lithium ore concentrates into uniform micro-particulate powders. | Consistent particle distribution and contamination-free stainless pathways maintain chemical precursor purity. |
Technical Specifications
| Parameter | KT-LX-100A | KT-LX-2X100A |
|---|---|---|
| Equipment Architecture | Single-Bowl Continuous Pulverizer | Dual-Bowl High-Capacity Continuous Pulverizer |
| Number of Grinding Bowls | 1 | 2 |
| Feeding Method | Automated Continuous In-Line Feeding | Automated Continuous In-Line Feeding |
| Maximum Feed Particle Size | ≤15 mm | ≤15 mm |
| Final Discharge Particle Size | ≤80–200 mesh (<0.2 mm) | ≤80–200 mesh (<0.2 mm) |
| Sieving Pass Rate | ≥99.98% | ≥99.98% |
| Grinding Capacity | 150 g/min | 300 g/min (150 g/min × 2) |
| Receiver Container Volume | 5 kg | 10 kg (5 kg × 2 containers) |
| Main Drive & Sub-Motor Power | 1.5 kW + 0.75 kW | 1.5 kW + 0.55 kW |
| Material Contact Metallurgy | Certified AISI 304 Stainless Steel | Certified AISI 304 Stainless Steel |
| Pneumatic / Draft Evacuation System | Variable Frequency Drive (VFD) Controlled | Variable Frequency Drive (VFD) Controlled |
| Operating Power Supply | 380 V AC, 3-Phase, 5-Wire, 50/60 Hz | 380 V AC, 3-Phase, 5-Wire, 50/60 Hz |
| Equipment Weight | 280 kg | 390 kg |
| Overall External Dimensions (W × D × H) | 860 mm × 820 mm × 900 mm | 1080 mm × 900 mm × 950 mm |
Why Choose This Product
- Industrial Operational Throughput: By moving away from slow, batch-by-batch bowl preparation, this pulverizer multiplies sample preparation output, reducing labor costs and eliminating bottlenecks in fast-paced testing laboratories.
- Certified Sample Representation: Built-in mechanical splitting automatically isolates representative fractions during continuous milling, avoiding manual coning and quartering errors to deliver audit-ready sample accuracy.
- Dust-Free, Clean Working Environment: Complete structural encapsulation paired with a precision variable-frequency induced draft system guarantees a clean, compliant workspace free of airborne mineral dust.
- Zero Cross-Contamination Architecture: High-grade 304 stainless steel product contact zones coupled with automated pneumatic clearing cycles protect analytical integrity across differing sample grades.
- Turnkey Integration Capability: The machine interfaces directly with primary industrial crushers to establish a continuous, single-operator crushing, pulverizing, splitting, and bottling station.
Contact our technical engineering team today to request a comprehensive quotation or discuss integrating this continuous sample preparation system into your laboratory workflow.
