cooling circulator & heater circulator
30L Chilling Circulator Low temperature constant temperature reaction bath
Item Number : KCP-30
Price varies based on specs and customizations
- Fluid Volume
- 30 L
- Working Temp
- -120-5 ℃
- Pump Flowrate
- 35 L/min 4-6m
- Temp. Stability
- +/-2 ℃
Shipping:
Contact us to get shipping details Enjoy On-time Dispatch Guarantee.
Applications
KinTek KCP chilling circulator is an ideal functional chilling equipment , besides supplying constant chilling power with circulating fluids, it can also work as a one chilling bath to meet different working circumstances.
Its chilling system applies brand refrigerating compressor, high efficient heat exchangers, which can create a stable and quiet chilling power, max. Chilling temperature can be up to -120℃.
Its circulating system applies built in brand circulating pump, equipment standard inlet and outlet ports, which guarantee a reliable circulating result.
Detail & Parts
 |
 |
 |
 |
Technical specifications
| Model | Fluid Volume | Working Temp. | Cooling Capacity | Pump Flowrate | Temp. Stability | Hose Port | Dimensions (mm) |
| KCP30-20 | 30L | -23-5℃ | 3780-1150W | 35L/min 4-6m | +/-2℃ | 1/2’’ | 940*710*1010 |
| KCP30-30 | -32-5℃ | 3960-1200W | |||||
| KCP30-40 | -40-5℃ | 4080-1270W | |||||
| KCP30-60 | -63-5℃ | 4330-680W | 1030*810*1020 | ||||
| KCP30-80 | -83-5℃ | 4679-422W | |||||
| KCP30-120 | -120-5℃ | 4968-330W | 1150*850*1100 |
Warnings
Operator safety is the top important issue! Please operate the equipment with cautions. Working with inflammable& explosive or toxic gases is very dangerous, operators must take all necessary precautions before starting the equipment. Working with positive pressure inside the reactors or chambers is dangerous, operator must fellow the safety procedures strictly. Extra caution must also be taken when operating with air-reactive materials, especially under vacuum. A leak can draw air into the apparatus and cause a violent reaction to occur.
Designed for You
KinTek provide deep custom made service and equipment to worldwide customers, our specialized teamwork and rich experienced engineers are capable to undertake the custom tailoring hardware and software equipment requirements, and help our customer to build up the exclusive and personalized equipment and solution!
Would you please drop your ideas to us, our engineers are ready for you now!
FAQ
What Is A Cold Trap Chiller In Lab?
What Is A Cooling Circulator?
What Is The Purpose Of A Cold Trap Chiller?
What Is A Heated Circulator?
What Is A Circulating Water Bath?
Why Is A Cold Trap Placed Before The Vacuum Pump?
What Is The Purpose Of A Heater Circulator?
How Does A Cooling Circulator Work?
How Does A Heater Circulator Work?
What Are The Advantages Of Using A Cooling Circulator?
What Types Of Fluids Can Be Used With A Heater Circulator?
What Safety Precautions Should Be Taken When Using A Cooling Circulator?
Can A Heater Circulator Be Used For Cooling Applications?
